Pneaumatic Driven Piston Hot Filling Machine
|Material:||SS304 And SS316|
|Contrl System||PLC and Touch screen|
Pneaumatic Driven Piston Hot Filling Machine, volumetric piston filler, Hot Fill Machine For Sticky Liquid
This hot filling machine is specially made for viscous liquid such as concentrated jucie , honey, butter, cream, Semi-liquids or paste – sauces, soups, salad dressings, paint, detergent, liquid soap, gels applied to bottleof all sizes. It is widely used in industries such as food, beverage, cosmetics etc.
- The Piston filling machine is designed by our company in the reference overseas similar product, and adds some additional function, which makes the product more simple and convenient in operation, adjustment, cleaning and maintenance.
- The liquid filling machine is reasonable in design, simple and beautiful in appearance, and easy in filling volume adjustment.
- The parts contacted with material are made of 304L or 316L stainless steel.
- No bottle no filling. Equiped with count function.bottle positioning system and liquid level control system.
- Adopting German FESTO, Taiwan AirTac pneumatic components and Taiwan's electrical control parts, the performance is stable.
This liquid piston filling machine is full automatically, It is suitable for all kinds of bottles, no matter plastic or glassboth round and square are OK. Connecting with capping and labeling machine can form a wholeproduction line.
The liquid filling machine is reasonable in design, simple and beautiful in appearance, and easy in fillingvolume adjustment. Adopting bottle positioning system and liquid level control system, adopting German FESTO, Taiwan AirTac pneumatic components and Taiwan's electrical control parts, the performance is stable.
Machine can be customized according to customer's request. We produce machine according to the bottle sample so that finished machine can be perfectly suitable for your products. We take workingvideo with your samples for you to check after machine finished.
We use the best components, CE standard, all metal parts are made of stainless steel, which makes machine stable and durable, meet the standard of GMP. We have exported many machines to many countries abroad, customers’ response are good. Finished machine are packaged in strong seaworthy wooden cases.
This machine is with a hopper on the top, specially suitable for filling viscous liquid such as cream Paste, tomato paste,peanut butter etc. The hopper is to store the liquid, made of SS304(SS316 is optional), double jacket, hasfunction of heating and keeping warm. This guarantee the fluidity of liquid. Equipped with piston pumps, specially suitable for viscous liquid.
|Filling material||Honey, Tomato Paste, Butter, etc.|
|Filling nozzles||2/4/6/8 nozzles(can be customized by customers)|
|Filling Volume||30-2000ml( can be customized by customers)|
|Polyester Bottle Standard||bottle diameterΦ50-Φ500; height 50-500|
|Filling precision||±1%(Liquid level)|
|Gas Source Pressure||2~3MPa|
|Single machine noise||≤50dB|
|Hopper||SS304,double jacket,keeping warm|
Application of Piston Filler:
Volumatic Piston Filling machine Widely used for filling paste, such as: pigments, syrup, oral liquid, sauce, shampoo, fruit juice, colloids, white latex, laundry detergent, shampoo, detergent, hand soap, conditioner and other semi-fluid and viscous or corrosive paste liquid filling, there are many A variety of filling volumes are available.
